• 1.Acceleration/Velocity/Displacement;
  2.Screen flipping;
  3.Switch acceleration measurement between high and low frequency;
  4.high frequency (1KHz~4KHz) /low frequency (10Hz~1KHz)
  5.Curve display;
  6.Store and view files;
  7.Power indicator;
  8.Double measurement button;
  9.Flashlight;
  10.Brightness control;
  11.Select Chinese/English;
  12.Shutdown time setting;
  13.Selection of machine level;
  14.Measurement of vibration frequency.

• Technical parameters	Technical indicators
  Vibration acquisition	Piezoelectric ceramic accelerometer (shear type)
  Measurement range	Acceleration：0.1~199.9m/s2 Velocity：0.1~199.9mm/s Displacement：0.001~1.999mm Frequency:0Hz~4KHz
  Measurement accuracy	±10%
  Frequency range of acceleration measurement	High frequency：1KHz～4KHz (HI)   Low frequency：10Hz～1KHz ( LO)
  Frequency range of speed measurement	10Hz～1KHz (LO)
  Frequency range of displacement measurement	10Hz～1KHz (LO)
  Maximum groups of data storage	500 pieces (5 groups * 100 pieces/group)
  Power supply	1.5V AAA battery*2
  Temperature range for operation	0~40℃
  Humidity range for operation	30~90%RH
  Size	180x54x30mm
  Weight	>150g(with batteries)



• Please refer to the manual for details
•
•
